Drivers
LF: 4 x 8" Neodym woofer with 2,5" voice coil
HF: 4 x 1" Neodym compression driver with 1,75" voice coil

Frequency range
56 Hz - 19 kHz (- 10 dB)
72 Hz - 16 kHz (+/- 3 dB)

Coverage range (h x v)
100° x 0°/ -20°

Impedance
LF: 8 Ω
HF: 8 Ω

Powerhandling (AES / Program / Peak)
LF: 1.000 W / 2.000 W / 4.000 W
HF: 160 W / 320 W / 640 W

Sensitivity 1 W/1 m
LF: 103 dB SPL
HF: 109 dB SPL

Sound pressure at (AES / Program / Peak)
130 dB SPL / 136 dB SPL / 139 dB SPL

Connection
2 x NEUTRIK NL4 IN/OUT 1+/1- (4-pole looped-through)

Finish
Polyurea coating in RAL 9005

Dimensions / Weight
1.336 (H) x 245 (W) x 336 mm (D) / 35,0 kg
