Drivers
LF: 2 x 8" Neodym woofer with 2,5“ voice coil
HF: 1 x 1,4“ Ferrit compression driver with 2,4“ voice coil

Frequency range
65 Hz - 19 kHz (- 10 dB)
78 Hz - 17,3 kHz (+/- 3 dB)

Coverage range (h x v)
90° x 40° or 60° x 40°

Impedance
4 Ω

Powerhandling (AES / Programm / Peak)
500 W /1.000 W / 2.000 W

Sensitivity 1 W/1 m
103 dB SPL

Sound pressure at (AES / Programm / Peak)
130 dB SPL / 133 dB SPL / 136 dB SPL

Connection
2 x NEUTRIK NL4 IN/OUT 1+/1- (4-pole looped-through)

Finish
Polyurea coating in RAL 9005.

Dimensions / Weight
625 (H) x 262 (W) x 337 mm (D) / 19,6 kg
