Drivers
LF: 1 x 10" Neodym Tiefmitteltöner mit 2,5" Schwingspule
HF: 1 x 1" Neodym Hochtöner mit 1,7" Schwingspule

Frequency range
70 Hz - 22 kHz (- 10 dB)
107 Hz - 21 kHz (+/- 3 dB)

Coverage range (h x v)
90° x 40° (rotatable and arrayable horns)

Impedance
8 Ω

Powerhandling (AES / Program / Peak)
350 W / 700 W / 1.400 W

Sensitivity 1 W/1 m
100 dB SPL

Sound pressure at (AES / Program / Peak)
125 dB SPL / 128 dB SPL / 131 dB SPL

Connection
4 x NEUTRIK NL4 IN/OUT 1+/- (4-pole looped-through)

Finish
Polyurea coating in RAL 9005.

Dimensions / Weight
520 (H) x 321 (W) x 267 mm (D) / 15,3 kg
