Drivers
12 x 4" Neodym wideband transducer with 0,75" voice coil

Frequency range
140 Hz - 18 kHz (- 10 dB)
185 Hz - 16 kHz (+/- 3 dB)

Coverage range (h x v)
70° x 14°

Impedanz
5,3 Ω

Powerhandling (AES / Program / Peak)
360 W / 720 W / 1.440 W

Sensitivity 1 W/1 m
101 dB SPL

Sound pressure at (AES / Program / Peak)
126 dB SPL / 129 dB SPL / 132 dB SPL

Connection
2 x NEUTRIK NL4 IN/OUT 1+/- (4-pole looped-through)

Oberfläche
Polyurea coating in RAL 9005.

Dimensions / Weight
1.236 (H) x 119 (W) x 160 (D) mm / 9,2 kg
